Description:
It’s finally time! Our shipment of Butcher frames are officially on their way and we will start taking pre-orders today. All the frames include a seatpost, seatclamp, integrated headset and mid bottom bracket. Otherwise if you want an all new ride we will be selling them as complete bikes too. Choose your options and have it built to your specifications. We teamed up with Fyxation on this and we’re outfitting all the complete builds with the new 35c Session 700’s. Like the 700×28 sessions, these tires feel a little bigger than 35c and have the quality you would expect out of a Fyxation tire. Below are some pictures and specs. Check out the Butcher page on our site and click the BUY ONLINE tab to place your pre-order.
Orders will start shipping the week of February 21.”
Details:
Release Date:
- March 2011
Manufacturer:
- Eighthinch
MSRP: $799
Color(s):
- Metallic Rootbeer
- Raw
Size(s):
- 50cm
- 53cm
- 56cm
- 59cm
Wheel Size:
- 700c
Gallery:
Specifications:
- BUTCHER Specs:
- Made from 4130 Double Butted Cromoly Tubing
- Fits tires up to 50c
- 10mm Dropouts
- Removable cable guides & rear 990 brake mounts
- 1 1/8″ Integrated headtube
- 120mm Rear Spacing
- Mid Bottom Bracket
- Double crimped chainstays for Left or Right side drive and extra clearance
- Weight (56cm) 5.3lbs [2400 grams] (frame only)
- Stock Build Choices:
- Frame Color: Metallic Root Beer or Raw ($25 Extra). Sizes: 50, 53, 56, or 59cm
- Fork: SE Landing Gear
- Wheels: EighthInch Julian’s with Formula Sealed Bearing Hubs. Machined or Non-Machined Sidewalls
- Note: Black and White wheels come with Black hubs except Silver- which come with Silver Hubs
- Handlebars: EighthInch Freestyle Bars or Riser Bars
- Stem: EighthInch Freestyle Stem
- Tires: Fyxation Session 700 x 35c
- Crankset: EighthInch BMX Spline Drive
- Chain: EighthInch Half-Link
- Saddle: Odyssey Senior
- Pedals: EighthInch Track Pedals or EightInch Plastic Pedals
- Note: Toe Clips Not Included But Highly Recommended!!!(Clips and straps do not work with plastic pedals)
- Grips: EighthInch Street Grips
- Cog or Freewheel
- Alloy Seatpost
- Sealed Mid Bottom Bracket
- Sealed Integrated Headset
- Presta Valve Tubes
- Front Brake & Lever Included and Installed
- * BIKE BUILD UPGRADES *
- Fyxation Grips & Bar Ends – Protect your bars and add some color to your ride
- Bash Guard – Bolts on to our spline sprocket. Save your chain when you do sprocket tricks or play polo!
- Double Toe Clips & Straps – The best upgrade you can do! Stay safe and keep your feet on those pedals! (straps not compatible with plastic pedals)
- KNOG Beetle Lightset – Ride at night? Add visibility and flair to your bike with these colorful KNOG Lights
- YOUR BIKE WILL BE HAND BUILT BY OUR MECHANIC AND SHIPPED WITHIN 3-5 BUSINESS DAYS
- Geometry Specs:
| Size in CM | 50cm | 53cm | 56cm | 59cm |
| Seat Tube Center-Top | 50cm | 53cm | 56cm | 59cm |
| Top Tube Actual | 57.1cm | 57.9cm | 58.3cm | 59.5cm |
| Top Tube Virtual | 58.2cm | 58.7cm | 59.2cm | 60.2cm |
| Head Tube Angle | 74.5 | 74.5 | 74.5 | 74.5 |
| Seat Tube Angle | 74 | 74 | 74 | 74 |
| BB Drop | 45mm | 45mm | 45mm | 45mm |
| Chainstay Length | 410mm | 410mm | 410mm | 410mm |
| Headtube Length | 95mm | 110mm | 150mm | 170mm |
