Description:
The Scissor has been born from the demand for a tough fixed gear bike for the likes of team riders Super Ted and Tom La Marche to thrash around their respective city landscapes.
The frame is constructed from Tange Prestige cro-mo, is much lighter than the Plug and has a longer cockpit, steeper head angle, lower stand-over height and slightly higher bottom bracket.
Details:
Release Date:
- September 2011
Manufacturer:
- Charge Bikes
MSRP: n/a
Color(s):
- Gloss Black
Size(s):
- Small
- Medium
Wheel Size:
- 700c
Gallery:
Specifications:
- Frame: Tange Prestige, Seamless, Double butted cro-mo
- Fork: Charge Scissor, Tange Infinity cro-mo
- Rear Shock: N/A
- Chain Device: N/A
- Chainset: BMX 3-pc, 10 spline
- Bottom Bracket: Mid, sealed
- Pedals: eclat Surge PC
- Front Der: N/A
- Rear Der: N/A
- Shifters: N/A
- Cassette: TBC
- Chain: 1/8″ Shortlink
- Rims: Deep V
- Front Tyre: Charge Coaster, 700x32c
- Rear Tyre: Charge Coaster, 700x32c
- Front Hub: Charge Single Speed, sealed bearing
- Rear Hub: Charge FS Fixed/FW, 10T
- Spokes: 14G STAINLESS
- Nipples: BRASS
- Front Brake: Caliper type
- Rear Brake: Caliper type
- Brake Levers:BMX type
- Handlebar: Charge Scissor wide bar
- Stem: BMX type
- Grips: Éclat Team grip
- Headset: FSA TH-875
- Saddle: Charge Bucket
- Seat Post: Alloy, single bolt
- Seat Clamp: Shield, bolt type
Geometry:
| Small | Medium | |
| Top tube length | 552mm | 564mm |
| Head angle | 71.5° | 71.5° |
| Head tube length | 98mm | 113mm |
| Seat tube length | 495mm | 525mm |
| Seat angle | 73° | BB Shell | 73mm |
| Seat clamp | 30mm | BB drop | 25.4mm |
| Seat post size | 27.2mm | BB Type | Mid |
| Chain stay length | 440mm | Tyre Clearance | 75mm |
