Charge Scissor Frame

Description:

The Scissor frame and fork has been born from the demand for a tough fixed gear bike for the likes of team riders Super Ted and Tom La Marche to thrash around their respective city landscapes.


The frame is constructed from Tange Infinity butted steel. It is much lighter than the Plug and has a longer cockpit, steeper head angle, lower stand-over height and slightly higher BB.

  • With input from SuperTed and Tom La Marche, Charge concocted the ideal urban freestyle frame
  • Longer top-tube, steeper head angle and 1.5″ lower stand-over height make for perfect geometry built for thrashing
  • Tange Prestige double butted CrMo frame (lighter than standard Plug). Fork sold separately
  • Both sizes have a 64mm bottom bracket height, 50mm rear tire clearance
  • Medium frame recommended for those over 5 ft 10 in. Weight: TBA
  • 2-tone grey paint (light grey chainstays, downtube gusset and brake bridge), with highlighted welds, seat collar not included




Details:

Release Date:

  • December 2009

Manufacturer:

  • Charge Bikes

MSRP: $450

Colors:

  • 2-Tone Grey

Size(s):

  • S (48cm)
  • M (51cm)

Wheel Size:

  • 700c

Gallery:

Specifications:

  • Effective top tube length: S: 576mm M: 586mm
  • Head angle: 71.5?
  • Head tube length: S: 124mm M: 139mm
  • Seat angle: S: 73? M: 74?
  • Seat tube length: S: 487mm M: 519mm
  • Seat clamp: 30mm
  • Seat post size: 27.2mm
  • Chain stay length: 405mm
  • Front mech size: N/A
  • BB Shell: 68mm
