BMW Gangsta Track Frame

Description:

A.K.A “THE GANGSTA!”

The idea for the original Gansta started over a decade ago when riding our 1960s English track Iron. Starting from scratch, we wanted to design a bike that maintained the nimble handling of traditional track geometry, but without the normal pitfalls of toeverlap and low speed oversteer – and it had to be stout enough to race and
work on 7 days a week.


The first prototypes were sent for testing in the streets of London, Tokyo, and backalleys of NYC. After a few messenger-refined tweaks and countless hours of CAD work, the Gangsta was born

Details:

Release Date:

  • 2007

Manufacturer:

  • Brooklyn Machine Works

MSRP: $775

Colors:

  • Black
  • White
  • Grey

Size(s):

  • 40cm
  • 46cm
  • 50cm

Wheel Size:

  • 700c

Gallery:

Specifications:

40CM

* Measured W | 700 × 23 Tires

  • SEAT TUBE: C t0 C 40cm / 15.7In
  • C to T 48cm / 18.8in
  • (B1) TOP TUBE (ACTUAL): 53cm / 20.8in
  • B2 IOP TUBE (EFFECTIVE): 56cm / 22in
  • C MIN. CHAINSTAY: 40cm / 15.7in
  • D FORK RAKE: 34mm / 1.3in
  • E HEAD TUBE ANGLE: 73.5°
  • F SEAT TUBE ANGLE: 73°
  • G MIN. WHEELBASE: 97.6cm / 38.4in
  • (A) STANDOVER HEIGHT: 76cm | 29.9
  • BB HEIGHT & DROP: 282.6mm & 57mm
  • 11.13in & 2.24in
